Stainless Steel

D735997

REACTOR, 13,000 GALLON, 316L, JKT, 30 PSI, AGIT, INCONEL,

REACTOR, 13,000 GALLON CAPACITY, 316L STAINLESS STEEL CONSTRUTION, INCONEL JACKET, MEASURES 11' DIAMETER X 17' HIGH, DISHED TOP & BOTTOM. RATED FOR 30 PSI @ 420 DEG. F INTERNAL. COMPLETE WITH AGITATOR DRIVEN BY 150 HP MOTOR, LEADING TO 316L S/ST AGITATOR ... Learn More

D735794

REACTOR, 10,000 GALLON, S/ST, JKT, AGIT, 90 PSI

REACTOR, 10,000 GALLON CAPACITY, 304L STAINLESS STEEL CONSTRUCTION, RATED FOR 90 PSI/FV @ 600 DEG. F INTERNAL, JACKETED AND RATED FOR 300 PSI @ 600 DEG. F., -20 DEG F. MDMT. MEASURES 10-1/2' DIAMETER X 12' HIGH. REPORTED TO BE IN GOOD CONDITION.
... Learn More

D735986

REACTOR, 10,000 GALLON, 316L S/ST, JKT, AGIT, 110 PSI, (3)

(3) REACTOR, 10,000 GALLON, 316L STAINLESS STEEL CONSTRUCTION, MANUFACTURED BY BRIGHTON, RATED FOR 110 PSI/FV AT 300 DEG F. INTERNAL, JACKETED FOR 50 PSI AT 100 DEG F. ALSO INCLUDES INTERNAL SET OF PLATE COILS RATED FOR 100 PSI AT 300 DEG F., MEASURES 10-... Learn More

S631500

REACTOR, 3,500 GALLON, 347 S/ST, 8'6" X 7', JKT,

3,500 GAL 347 S/ST CLAD REACTOR, 8'6" DIAMETER X 7' STRAIGHT HEIGHT, RATED 15 PSI OR FULL VACUUM INTERNAL. VESSEL HAS 50 PSI CARBON STEEL JACKET ON BOTTOM & 2/3 SIDE. TANK IS AGITATED BY 3 HP MOTOR & FALK REDUCER WITH 4' DIAMETER & 2' DIAMETER 4 BLADE AGI... Learn More

Z631765

REACTOR, 3,000 GALLON, 316 S/ST, BLAW KNOX, AGIT, COILS,

REACTOR, 3,000 GALLON, BLAW-KNOX, 316 STAINLESS STEEL, 8'DIA X 10' STRAIGHT SIDE, HAS TURBINE TYPE AGITATOR WITH MECHANICAL SEALS (40 HP MOTOR AND REDUCER ARE NO LONGER AVAILABLE). JACKET RATED FOR 35 PSI, BODY RATED FOR 150 PSI, 4" CENTER BOTTOM DISCHARG... Learn More

S631805

REACTOR, 3,000 GALLON, S/ST, COILS, AGITATOR,

REACTOR, 3,000 GALLON, STAINLESS STEEL, 8' DIAMETER X 8' STRAIGHT HEIGHT WITH DISHED HEADS. LUG MOUNTINGS. REACTOR HAS (10) TURNS OF 2" DIAMETER STAINLESS STEEL COIL AROUND INSIDE OF TANK FOR HEATING/COOLING. AGITATOR IS TOP MOUNTED, STAINLESS STEEL SHAFT... Learn More

S632000

REACTOR, 2,200 GALLON, S/ST, 6' X 10', 120 PSI, JKT, AGIT,

2,200 GALLON 304 STAINLESS STEEL REACTOR, 6' DIAMETER X 10' STRAIGHT HEIGHT, RATED 120 PSI INTERNAL. VESSEL HAS 25 PSI JACKET (CARBON STEEL). TANK IS AGITATED BY A HYDRAULICALLY DRIVEN CHEMINEER AGITATOR WITH A 3 BLADE RETREATING CURVED AGIT & A 4 BLADE 2... Learn More

Z636110

REACTOR, 1,000 GALLON, S/ST, 5' X 8', 695 PSI, COILS,

1,000 GALLON AUTOCLAVE, 304 STAINLESS STEEL, 5' X 8', DISH TOP AND BOTTOM, 695 PSI INTERNAL WORKING, 2 FULL SETS OF INTERNAL COILS, 2" DIA X 16 TURNS EACH, AGITATOR WITHOUT MOTOR, 3" SHAFT, 4 BLADE PADDLE PROP, 25" DIA. (2) 2" FLANGED INS, (2) 2" FLANGED ... Learn More

C636375

REACTOR, 850 GALLON, S/ST, 50 PSI INT, JKTD, AGIT, 5 HP,

REACTOR, 850 GALLON, TYPE 304L STAINLESS STEEL, 5' ID X 6' STRAIGHT SIDE, MANUFACTUERED BY BENICIA FABRICATION & MACHINE, 50 PSI/FV @ 450 F INTERNAL, 60 PSI @ 450 F JACKET (2' BOTTOM JACKET), COOLING COIL INSIDE. COMPLETE WITH 5 HP PHILADELPHIA AGITATOR. ... Learn More

C636380

REACTOR, 850 GALLON, S/ST, 60 PSI INT, JKTD, AGIT, (2),

(2) REACTOR, 850 GALLON, TYPE 304L STAINLESS STEEL, 5' ID X 6' STRAIGHT SIDE, MANUFACURED BY SARACCO TANK & MFG., 60 PSI/FV @ 450 F INTERNAL, 75 PSI @ 450 F JACKET, COOLING COIL INSIDE. COMPLETE WITH 5 HP AGITATOR THRU RIGHT ANGLE GEAR BOX. LUG MOUNTED, 3... Learn More

C637519

REACTOR, 500 GALLON, 316 S/ST, TOP ENTERING AGITATOR,

REACTOR, 500 GALLON, 316 S/ST, TOP ENTERING AGITATOR, INDUSTRIAL PROCESS ENG., 50 PSI INTERNAL, 75 PSI JACKET, TOP 18" DIA MANHOLE, 2 - 1" DIA TOP FLANGES, 1 - 3" DIA TOP FLANGE, 1 - 6" DIA TOP FLANGE, 2-1/2" CENTER BOTTOM OUTLET, ON LEGS.... Learn More

S693105

REACTOR, 320 GALLON, S/ST, 34" X 75", AGIT, 150 PSI, JKT,

REACTOR, 320 GALLON, 304 STAINLESS STEEL, 34" DIA. X 75" STRAIGHT SIDE, RATED FOR 50PSI/FV @ 350F, DISHED TOP & BOTTOM, DIMPLED JACKET, RATED FOR 150 PSI @ 350F, MFG BY D&W WELDING, 5 HP, 230/460V, 1740 RPM BELT DRIVEN MOTOR THRU 25:1 RIGHT ANGLE GEAR RED... Learn More

S733456

REACTOR, 300 GALLON, 304 S/ST, C.E. HOWARD, 50 PSI, JKTD,

REACTOR, 300 GALLON CAPACITY, 304 STAINLESS STEEL CONSTRUCTION, DISHED TOP & BTM, MEASURES 40" DIA. X 60" DEEP, MANUFACTURED BY C.E. HOWARD, MODEL WPXR, COMPLETE WITH PADDLE AGITATION WITH (2) 4-BLADE PADDLES ON CENTER AND BOTTOM OF 1-1/2" SHAFT, DRIVEN B... Learn More

S640100

REACTOR, 175 GALLON, S/ST, JKTD, AGIT

REACTOR, 175 GALLON, STAINLESS STEEL, JACKETED FOR 100 PSI @ 338 DEG F ATMOSPHERIC PRESSURE INTERNAL. 3-1/2" DISHED BOTTOM WITH CENTER BOTTOM DISCHARGE, FLAT TOP REMOVABLE WITH LOCKING CLAMPS, TOP INLETS 1 @ 1 3/4", 1 @ 5" AND 1 @ 8". REACTOR HAS CENTER M... Learn More

L735548

REACTOR, 132 GALLON, S/ST, 30" X 48", AGIT, JKT, 30 PSI,

BIOTECH REACTOR, 500 LITER (132 GALLON) CAPACITY, STAINLESS STEEL CONSTRUCTION, 30" DIAMETER X 48" STRAIGHT SIDE, DISH TOP & SLIGHT CONE BOTTOM, MANUFACTURED BY SANTA ROSA STAINLESS, RATED FOR 30 PSI AT 250 INTERNAL, JACKETED FOR 90 PSI AT 330 PSI. INCLUD... Learn More

S640650

REACTOR, 125 GALLON, S/ST, JKTD,

REACTOR, 125 GAL, STAINLESS STEEL, JACKETED, AGITATED. INTERNAL DIMS: 27" x 4' STRAIGHT SIDE. INTERNAL RATING 40 PSI @ 275 DEG F. JACKET RATING 30 PSI @ 275 DEG F, FULL JACKET STRAIGHT SIDE, NO BOTTOM JACKET. BOLT ON DOME TOP, 2 SITE GLASS, VARIOUS INLETS... Learn More

L735743

REACTOR, 100 GALLON, 316 S/ST, JKT, AGIT, MUELLER, 50 PSI, (4)

(4) REACTOR, 400 LITER (105 GALLON), 316 STAINLESS STEEL CONSTRUCTION, MUELLER, RATED FOR 50PSI/FV @ 302F, 32 MDMT, JACKETED AND RATED FOR 100 PSI @ 302F, 36" DIAMETER X 36" STRAIGHT SIDE, DISHED TOP AND BOTTOM, 2-1/2" CENTER BOTTOM OUTLET TAPERED TO 1". ... Learn More

C736112

REACTOR, 75 GALLON, S/ST, JKT, DCI, 32" x 30"

REACTOR, MFG BY DCI, 75 GALLON, STAINLESS STEEL, JACKETED FOR 55 PSI @ 150 DEG F ATMOPHERIC PRESSURE INTERNAL, 115 PSI @ 347 DEG F ON JACKET. DISH BOTTOM WITH 2" CENTER BOTTOM OUTLET, DISH TOP WITH 5 @ 1" TOP INLETS AND 1 @ 2" TOP INLET, DOG LOCKING. UNIT... Learn More

L735549

REACTOR, 66 GALLON, S/ST, 30" X 48", AGIT, JKT, 30 PSI,

BIOTECH REACTOR, 250 LITER (66 GALLON) CAPACITY, STAINLESS STEEL CONSTRUCTION, 24" DIAMETER X 36" STRAIGHT SIDE, DISH TOP & SLIGHT CONE BOTTOM, MANUFACTURED BY SANTA ROSA STAINLESS, RATED FOR 30 PSI AT 250 INTERNAL, JACKETED FOR 90 PSI AT 330 PSI. INCLUDE... Learn More

Z640995

REACTOR, 60 GALLON, S/ST, C.E. HOWARD, CARBON STEEL JACKET,

REACTOR, 60 GALLON, S/ST, C.E. HOWARD, CARBON STEEL JACKET, TURBINE AGITATOR, LESS DRV, SHELL 60 PSI/FULL VACUUM @ 300 DEG. F., TEST 105 PSI @ 300 DEG. F., JACKET 60 PSI, TEST 140 PSI @ 300 DEG. F., ASME, 7" X 13" OVAL MANWAY, 2 - 4" DIA SITE GLASSES, 2-1... Learn More

C735494

REACTOR, 50 GAL, S/ST, CHERRY BURRELL, JKT, 30 PSI

CHERRY BURRELL STAINLESS STEEL 50 GALLON JACKETED REACTOR. UNIT IS RATED FOR 30 PSI @ 350 DEG F, WITH MAX EXTERNAL PSI OF 15 @ 350 DEG F. UNIT HAS DOME TOP/ DISH BOTTOM WITH (3) 3/4" TOP FLANGE, 1-1/2" TOP SANITARY FITTING. UNIT HAS MIXER ON SIDE BOTTOM, ... Learn More

Z641200

REACTOR, 30 GALLON, 316 S/ST, 18" X 24", 45 PSI, JKT,

PFAUDLER 316 S/ST. REACTOR, 30 GALLON CAPACITY, 18" DIAMETER X 24" HIGH, WITH DISHED TOP AND BOTTOM HEADS, RATED 45 PSI INTERNAL. REACTOR HAS 75 PSI, 20" HIGH CARBON STEEL JACKET. MOUNTED ON LEGS. S/N E3591987(60). REMOVABLE CLAMP-ON TOP HEAD. 3" CENTER B... Learn More

L735263

REACTOR, 30 GALLON, S/ST, JKT, AGIT, LEE, 160 PSI

REACTOR, 30 GALLON (114L), ALL STAINLESS STEEL CONSTRUCTION, MANUFACTURED BY LEE, MODEL 30U, DISHED TOP AND BOTTOM, 1-1/2" CENTER BOTTOM OUTLET, VESSEL RATED FOR 160 PSI @ 287ºF INTERNAL, JACKETED FOR 100 PSI @ 338ºF, MDMT -20ºF. COMPLETE WITH LIGHTNIN... Learn More

S641300

REACTOR, 25 GALLON, S/ST, JKT, 14" X 32", (2),

(2) 25 GALLON REACTORS MOUNTED ON A COMMON STAND. 14" DIAMETER X 32" HIGH REACTION VESSELS WITH DISHED BOTTOMS AND FLAT CLAMP-ON TOPS. JACKETED FOR 21" ON THE SIDES ONLY. INCLUDES A 3/8" STAINLESS STEEL CENTRIFUGAL PUMP WITH FRACTIONAL HP. ... Learn More

S735146

REACTOR, 22 GALLON, S/ST, PRECISION, AGIT., JKT, 50 PSI, (2)

(2) REACTOR, 85 LITER (22 GALLON) CAPACITY, 316L STAINLESS STEEL CONSTRUCTION, ELECTROPOLISHED INTERNALS, PHARMACEUTICAL GRADE, MANUFACTURED BY PRECISION STAINLESS. INTERNALLY RATED FOR 50 PSI AT 300/-20 F. VACUUM RATED FOR 15 PSI @ 300 F, JACKETED FOR 10... Learn More

A735087

REACTOR, 20 GALLON, S/ST, 750 PSI, AGIT, JKT, ACME,

REACTOR, APPROXIMATELY 20 GALLON CAPACITY, MEASURES 20" DIAMETER X 24" DEEP, INTERNALLY RATED FOR 750 PSI/FV @ 350F, JACKETED FOR 80 PSI @ 350F. DISHED TOP WITH BOLTED LID, DISHED BOTTOM WITH CENTER BOTTOM OUTLET. INCLUDES TOP MOUNTED S/ST AGITATOR, DRIVE... Learn More

L735261

REACTOR, 20 GALLON, S/ST, JKT, AGIT, LEE, 15 PSI,

REACTOR, 20 GALLON, ALL STAINLESS STEEL CONSTRUCTION, MANUFACTURED BY LEE MODEL 20U, DISHED TOP AND BOTTOM, RATED FOR 15 PSI @ 250F INTERNAL, JACKETED FOR 100 PSI @ 338F, MDMT -20F. COMPLETE WITH LIGHTNIN MODEL XJADS-33 PNEUMATIC AGITATOR, DEAD LUBRICATOR... Learn More

H733038

REACTOR, 18 GALLON, 316 S/ST, 70L, FERMENTER, (2),

(2) REACTOR, NEW BRUNSWICK SCIENTIFIC COMPANY FERMENTERS WITH 70 LITER WORKING CAPACITY, 316 STAINLESS STEEL VESSEL. INTERNAL 40 PSI @ 300 DEG F, JACKET 35 PSI @ 300 DEG F, UNIT INSULATED. BOTTOM DRIVEN AGITATION, V-BELT STYLE, 3 HP DRIVE MOTOR. COMPLETE ... Learn More

H733036

REACTOR, 15 GALLON, S/ST, BIO-REACTOR, JKTD

CHEMAP COMPANY BIO REACTOR, 15 GALLON, STAINLESS STEEL CONSTRUCTION. SHELL AND JACKET RATED 50 PSI/FV @ 302 DEG F. BOTTOM DRIVEN AGITATION 2.2 KW, 3 SETS OF DISCS W/PIN BARS FOR AGITATION AND BAFFLES. MFG 1987, LOOKS GREAT, NUMEROUS INLETS. S/N 10982/2. M... Learn More

Z641525

REACTOR, 15 GALLON, S/ST, BUTANE TANK, 300 PSI,

REACTOR, 15 GALLON, REACTION VESSEL, 14" DIAMETER X 22" STRAIGHT SIDE, TYPE 304 STAINLESS STEEL PRODUCT CONTACT PARTS. UNIT BUILT IN 1974 BY BUTANE TANK CORP. THIS REACTOR IS CODE CONSTRUCTED WITH AN INTERNAL PRESSURE RATING OF 300 PSI AT 300 DEGREES F. J... Learn More

S641500

REACTOR, 15 GALLON, S/ST, JKT, 12" x 32", (6)

(6) 15 GALLON REACTORS MOUNTED ON COMMON STAND, 12" DIA x 32" HIGH VESSELS WITH DISH BOTTOM, FLAT CLAMP ON TOP. JACKETED FOR 21" ON SIDE ONLY. INCLUDES ASSORTED INLETS FOR THERMOWELL, VACUUM, SPARGING TUBE, ETC. NO PRESSURE RATINGS INTERNAL OR JACKET, COM... Learn More

S641545

REACTOR, 10 GALLON, G/L, PFAUDLER, AGIT, JKT,

PFAULDER REACTOR, 10 GAL, MFG #E180-0476, NB# 39413. INTERNAL PRESSURE IS 150 PSI @ 650 DEG F, JKT. PRESSURE IS 120 PSI @ 350 F, JKT. PRESSURE 105 PSI WITH INTERNAL VAC. UNIT HAS TYPE 5015 GLASS SEAL COMPL MOUNTED ON A PORT CART W/ THE REACTOR TOP & REFLU... Learn More

L735265

REACTOR, 10 GALLON, S/ST, JKT, DCI, 150 PSI, (2)

(2) REACTOR, R&D VESSEL, 10 GALLON (40L), ALL STAINLESS STEEL CONSTRUCTION, MANUFACTURED BY DCI, INC., DISHED TOP AND BOTTOM, RATED FOR 150 PSI @ 335F INTERNAL, JACKETED FOR 145 PSI @ 364F, MDMT -20F. S/N JS1437A. EXCELLENT CONDITION. ... Learn More

H733037

REACTOR, 8 GALLON, S/ST, FERMENTER, 30 L, JKT, AGIT,

REACTOR, LAB FERMENTATION SYSTEM DESIGNED BY FERMENTATION DESIGN OF NEW BRUNSWICK. SYSTEM INCLUDES (2) 30 LITER 12" x 18" FERMENTERS RATED FOR 50 PSIG/FV @ 300F INTERNAL AND JACKET. FERMENTER IS EQUIPPED WITH 2 HP BOTTOM V-BELT AGITATION DRIVES, INCLUDES ... Learn More

S735147

REACTOR, 4 GALLON, S/ST, JKT, AGIT, 45 PSI, (2)

(2) REACTOR TANK, 15 LITER CAPACITY, ALL STAINLESS STEEL CONSTRUCTION, PHARMACEUTICAL GRADE, ELECTROPOLISHED INTERNALS, MANUFACTURED BY DCI, INTERNAL DIMS. APPROX. 14" DIA. X 14" HIGH. INTERNALLY RATED FOR 45 PSI AT 300º F/-20ºF, JACKETED FOR 115 PSI AT... Learn More

Z628360

REACTOR, CONTINUOUS, 316 S/ST, 15" X 115", LIGHTNIN,

REACTOR, CONTINUOUS, 316 STAINLESS STEEL CONTACTS, MEASURES 15" DIAMETER X 115" HIGH, 15 STAGE. MANUFACTURED BY MIXING EQUIPMENT CO. INTERNALLY RATED FOR 100 PSI @ 300 DEG. F. CARBON STEEL JACKET RATED FOR 100 PSI @ 300 DEG. F, ASME CODED. INCLUDES LIGHTN... Learn More

Z628350

REACTOR, CONTINUOUS, 8" X 10', 135 PSI, JKT, S/ST

REACTOR, CONTINUOUS, 8" X 10', JACKETED, SIDE SWEPT SUR- FACE AGITATOR, 135 PSI @ 650 DEG. INTERNAL & JACKET, STAINLESS STEEL. UNIT IS HORIZONTAL.... Learn More
